The HP-3250 is a High-Pressure Line Pump Like No Other

HP-3250 Specifications

Technical Specifications
Output: Rod Side144 yd3/hr110 m3/hr
Output: Piston Side126 yd3/hr96 m3/hr
Pressure: Rod Side2,205 psi152 bar
Pressure: Piston Side3,249 psi224 bar
Material Cylinder Diameter8"200 mm
Material Cylinder Stroke Length6' 11"2,100 mm
Max Strokes Per MinuteRod Side
Piston Side
28
19
Volume ControlZero - Full
Vibrator StandardOption
Hard-chromed Material CylindersStandard
Hydraulic SystemClosed-loop
Hydraulic System Pressure5,075 psi350 bar
Drive Cylinder Diameter6.3"160 mm
Rod Diameter3.5"90 mm
Maximum Size Aggregate2.4"60 mm
Fuel Tank Capacity100 L / 26.4 GAL

DY Concrete Pumps HP-3250 High Pressure Concrete Line Pump

The HP-3250 is a new high pressure line pump from DY Concrete Pumps that is designed with high-rise, and other large projects, in mind.

With an impressive output of 144 yards per hour, this high-pressure line pump is tailor-made for high-rise construction projects. Equipped with dual hydraulic coolers, it ensures optimal performance even in challenging conditions. The HP-3250 stands out as the most versatile high-pressure line pump in the industry, and is able to effortlessly switch between high and low-pressure pumping.

That’s the DY Difference.
